The new CS 250 s4 Cento subwoofer is the perfect enhancement to every sound system, to fully enjoy the authentic Hertz Sound Experience!
The R & D team, always at the forefront in the search for innovative solutions, with unfailing effort, succeeded in obtaining very powerful bass frequencies from ultra-compact sealed enclosures, optimizing all the electroacoustic parameters according to the target set: high performance with boxes starting from 16 l. for the 25 cm (10 in.) CS 250 model.
The 4Ω single voice coil configuration offers maximum compatibility with any type of amplification and an enclosure that houses more than one subwoofer.
The reduced depth, the compact magnetic group and the lack of rear decompression hole allow the box to be shaped around the subwoofer obtaining a depth close to the one of a speaker for maximum freedom of installation on any type of car.
| Size mm (in.) | 250 (10) |
| Power Handling – Continuous W | 300 |
| Power Handling – Peak W | 600 |
| Impedance Ohm | 4 |
| No Filter Component | SUBWOOFER |
| Voice Coil Ø | 35 (1.38) |
| Magnet size D x d x h mm (in.) | 120 x 45 x 34 (4.72 x 1.77 x 1.34) |
| Weight of one component kg (lb.) | 3,795 (8.37) |
| Magnet | High density flux ferrite |
| Cone | Polyproyilene |
| Xmech mm (in.) | 16,5 (0.65) |
| D mm | 216 |
| Xmax mm | 12,5 |
| Re Ohm | 3,6 |
| Fs Hz | 30 |
| Le mH | 3,33 |
| Vas I | 34,5 |
| Mms g | 154 |
| Cms mm/N | 0,18 |
| BL T*m | 13,7 |
| Qts | 0,52 |
| Qes | 0,56 |
| Qms | 9,4 |
| Spl dB | 84 |
| A | 270 mm | 10.63 in. |
| B | 231 mm | 9.09 in. |
| C | 132 mm | 5.2 in. |
| D | 115 mm | 4.53 in. |
| E | 260 mm | 10.24 in. |
| F | 28,3 mm | 1.11 in. |
